C12B CARTRIDGE FORMULATION
CYAN PGI-29C PC29-C
MAGENTA PGI-29M PC29-M
YELLOW PGI-29Y PC29-Y
PHOTOBLACK PGI-29PBK PC29-PK
PHOTOCYAN PGI-29PC PC29-PC
PHOTOMAGENTA PGI-29PM PC29-PM
RED PGI-29R PC29-R
DARK  GRAY PGI-29 DGY PC29-DGY
GRAY PGI-29GY PC29-GY
LIGHT GRAY PGI-29 LGY PC29-LGY
CHROMA OPTIMIZER PGI-29CO PC29-CO
MATTE BLACK PGI-29MK PC29-MBK
All PGI-29 colors used in this printer are Lucia compatible pigment inks. The Chroma Optimizer is pure resin base and has no pigments. Unlike other Canon compatible pigment inks, none of these inks exhibit any issues whatsoever with adherence or ruboff and clogging. This inkset is as reliable as the original.

The Pro-10 printer shares the same inks as the Pro-1 using 10 of the 12 colors the Pro-1 uses. The Pro-1 chooses to use more of the photo colors when rendering the same color as compared to the Pro-10. This allows finer control of color but at the same time it uses more ink and requires high quality papers that possess high ink limits to achieve the best possible results.

Unlike competing inksets (across the globe)  for the Pro-1, when Canon ICCs are used with the Precision Colors inkset neutral images are produced and the use of the Gray Scale option is allowed with some slight bias adjustments.  Let's take a look ( Link) However in reality, the purchaser of this caliber of printer will likely be using ICC profiles and we again are providing the user with profiles specifically tuned for 5 types of lighting conditions. We recommend that these be used for the highest quality image which the Pro-1 can provide when equipped with a good inkset.


REFILLING OPTIONS:

Using a proper refill adapter, the PGI-29 cartridge can easily be refilled with a syringe and a digital scale to confirm ink volume. Ink is simply injected into the cartridge till it is full. We stress that a proper adapter MUST be used or else there is a risk injecting ink into the incorrect chamber. We can provide such an adapter and it is inexpensive and there is no reason to not use a proper adapter.

There is  no resetter for the Canon OEM PGI-29 chips. You should NOT operate this printer without new chips at each refill.  Doing so will very rapidly fill the waste ink pad with ink and this internal part when full  is not user serviceable. You should always only use this printer with functioning chips.

In order to do so, you will need to install new aftermarket chips each time the cartridge is refilled. To allow these chips to fit properly into a Canon PGI-29 OEM cartridge, we recommend modifying the OEM cartridge by removing plastic material behind the chip area. Once this is done, chip changeouts take seconds to carry out.

Modifying the area behind the chip should be carefully done. Jose Rodriguez a well known printer enthusiast has gone to the trouble of acquiring OEM cartridges and modify them appropriately in his machine shop. He has these available available for sale.

There are aftermarket bodies and prefilled cartridges available but beware since these cartridges, while obviously not possessing the Canon highest precision moulded bodies also omit various features the original cartridges provide. One aspect is the little red light that is visible when the cartridge is inserted and recognized. The next important feature is the out of ink optical detector that is inside the real Canon cartridge. This piece of optical wizardry will help protect the printer in the event that a cartridge has physically run out ink even when the chips estimates it still might have some left. The fact that Canon has gone to the trouble of putting it there indicates that they consider it important.

Just like the Pro-100 and Pro-10 we cannot stress highly enough that original Canon cartridges are always the prime choice for refillers.

When more cartridges become available I will supply already modified, rechipped and refilled real Canon cartridges. Essentially prefilled ready to use cartridges. I estimate to have these available by Mid August 2016.





PC29_4ozSet
Click on image to enlarge
Be especially careful that the correct ink shades are used when refilling. If the incorrect color ink is injected, the complete contents of the cartridge will need to be disposed. If it was used in the printer, then a lot of cleaning cycles ( BAD) will be required to flush the incorrect color out of the ink lines. So do not double check the shade of the ink but TRIPLE CHECK before filling.
